Model
|
MX1 Pro
|
|
Shape features
|
Aluminium
|
|
Weight
|
1.5kg
|
|
Dimension
|
128*90*45mm
|
|
System / CPU
|
Linux / Quard core 1.4 GHz
|
|
Screen
|
7 Inch LCD with touch screen
|
|
Print Engine
|
original TIJ2.5 driver board
|
|
Max Definition
|
600PDI(Optional)
|
|
Spray nozzle
|
Thermal foaming inkjet 2.5
|
|
Printing direction
|
Adjustable with 360 degree, meet all kinds of production needs
|
|
Printing line
|
1-8 lines (adjustable)
|
|
Printing height
|
1.2mm-12.7mm
|
|
Printing distance
|
1-10mm Mechanical Adjustment (the best distance between the nozzle and printed object is 2-5mm)
|
|
Printing content
|
Text, time, batch number, serial, number, Picture, QR code,DM code, barcode,Database printing
|
|
Application
|
carton, bucket,pipe, cable, metal, plastic bag, glass,electronics, automotive parts
|
|
Printing length
|
2000 characters for each message, no limitation on length
|
|
Printing speed
|
60m/min
|
|
Ink type
|
Quick-dry environmental ink, water-based ink and oily ink, UV Ink
|
|
Ink color
|
black, white, red, blue, yellow, green, invisible
|
|
Ink volume
|
42ml (usually can print 800,000 characters)
|
|
Interface
|
USB,RS232, External Sensor,External Encoder,Alarm Light,WIFI (For S/W update only)
|
|
Power
|
100 to 240V AC input ,50/60Hz
|
|
Storage Space
|
The machine can store more than 1000 mass (external USB make the information transfer in a free way)
|
|
Working condition
|
Temperature:0 – 45 degree; Humidity: 10% – 80%
|
